Airless Putty Spray Machine

Electric Airless Spray Painting Machine ULTRABEST 20 Specification

Voltage
220 V

Power Rating
2200 W

Drive
Direct Drive Motor

Frame Type
Steel, Wheeled Frame

Motor Power
3 HP

Model No
ULTRABEST 20

Accuracy
High Material Transfer Efficiency

Noise Level
Less than 70 dB

Machine Type
Airless Spray Machine

Operating Temperature
5C to 45C

Production Capacity
Up to 500 m2/day

Connectivity Options
Standard Power Cord

Lubricating System
Self-Lubricating

Features
Portable, Easy cleaning, Adjustable pressure, High efficiency, Sturdy frame

Frequency
50 Hz

Cooling System
Air Cooling

Product Type
Airless Putty Spray Machine

Technology
Airless Spray Technology

Power Source
Electric

Power
2.2 kW

Pressure
200 bar / 20 MPa

Surface Treatment
Powder Coated

Dimension (L*W*H)
570 x 430 x 620 mm

Weight (kg)
49 kg

Color
Blue and Black

Usage & Applications
Putty Spray, Wall Texture, Paint Spraying

Spraying Distance
30-40 cm

Transportability
Foldable handle, compact design

Recommended Applications
Interior & Exterior walls, Ceilings, Large Surface areas

Hose Length
15 meters

Pump Material
Stainless Steel

Operator Requirement
Single person operation

Nozzle Size Support
Up to 0.035 inch

Packaging Details
Wooden Box/Packing Carton

Max Flow Rate
6 L/min

Material Compatibility
Putty, Emulsion Paint, Primer, Texture Coat

Servicing
On-site service support available

Operating Pressure Range
20-200 bar

Pump Type
High Pressure Plunger Pump

Safety System
Overload Protection

Recommended Viscosity
Low to high viscosity materials

About Electric Airless Spray Painting Machine ULTRABEST 20

Airless paint & putty sprayer is a high-pressure machine used for wall paint, primer, texture, waterproofing coating, and wall putty spray work. It gives fast work, smooth finish, less labour cost, and better coverage for construction and painting projects.

Advanced Plunger Pump Technology

The ULTRABEST 20 utilizes a high-pressure plunger pump made from stainless steel, ensuring resilience against corrosion and consistent high performance. This allows for the spraying of both low and high viscosity materials, making it versatile for a wide range of wall and ceiling preparations.

Optimized for Large Surface Coverage

With a maximum flow rate of 6 liters per minute and a 15-meter hose, the machine is ideal for covering extensive areas efficiently. Adjustable spraying distances of 30-40 cm ensure uniform application whether working in homes, commercial buildings, or industrial settings.

User Convenience and Transportability

Designed for solo operation, this machine combines overload protection, a foldable handle, and a compact frame for easy maneuvering and storage. Packaging options include sturdy wooden boxes or packing cartons to ensure safe delivery and handling at any location in India.

FAQ's of AIRLESS PUTTY SPRAY MACHINE ULTRABEST 20:

Q: How do I operate the AIRLESS PUTTY SPRAY MACHINE ULTRABEST 20 for optimal performance?

A: To operate the machine effectively, connect the 15-meter hose, attach the appropriate nozzle (up to 0.035 inch), and ensure your chosen material (putty, emulsion paint, primer, or texture coat) matches the recommended viscosity. Adjust the operating pressure between 20-200 bar as needed and maintain a spraying distance of 30-40 cm from the surface. Single-person operation is supported for ease of use.

Q: What materials can the ULTRABEST 20 spray, and what is the recommended viscosity range?

A: The machine is compatible with putty, emulsion paint, primer, and texture coat. It supports both low and high viscosity materials, allowing you to smoothly apply a variety of surface coatings for both interior and exterior projects.

Q: When should I use the AIRLESS PUTTY SPRAY MACHINE ULTRABEST 20?

A: This spray machine is best used when you need to quickly and uniformly coat large wall or ceiling surfaces for residential, commercial, or industrial applications. It is especially efficient for preparing interiors, exteriors, and expansive areas that require consistent coverage.

Q: Where can the ULTRABEST 20 be applied and transported?

A: The machine is suitable for use on a diverse array of surfaces, including interior and exterior walls and ceilings. Thanks to its foldable handle and compact design, it is easily portable, making it convenient for movement between job sites, whether for dealer, manufacturer, distributor, or retail use across India.

Q: What is the cleaning and maintenance process for the ULTRABEST 20?

A: After use, flush the system with a compatible cleaning agent to remove any residual material from the hose and pump. Periodically check the stainless steel pump and nozzles for blockages or wear. Regular maintenance ensures optimal flow and extends the machine's service life. On-site servicing support is available if required.

Q: What are the benefits of using this airless putty spray machine over traditional methods?

A: The ULTRABEST 20 delivers considerable time savings, uniform coverage, and reduced labor requirements by allowing single-operator use. It ensures precise spraying with minimal material wastage, improving both efficiency and finish quality compared to manual application with trowels or rollers.
